Hand - Held Pen Type Digital Multimeter With NCV Tester And 2000 Counts Display

  • 1
  • 2

Brand Name : PEAKMETER

Model Number : PM8211

Certification : CE

Place of Origin : China

MOQ : 1

Price : Negotiation

Payment Terms : T/T

Supply Ability : 150,000 Pcs Per Month

Delivery Time : 5-40 work days

Packaging Details : Product Size 205x38x29mm Product Weight Approx. 110g

Product Name : Auto Range Digital Multimeter

Display : 2000 Counts

Work Light : YES

Diode Test : YES

NCV : YES

Continuity : YES

Contact Now

Hand - Held Pen Type Digital Multi-Meter With NCV Tester And 2000 Counts Display

English User Manual:https://drive.google.com/open?id=1RzIgeeqGrfGusaRSRsWI6JkB6KDQpgVA

Features:

Reminder: The Pen Style Digital Multimeter is shipped without batteries and color retail box.

This pen type digital multimeter is a safe and reliable measuring device. The instrument measures DC voltage, DC current, AC current, resistance, diode and connectivity:with non contact voltage detection function and safety reminders.
Key features:

  1. Display: 3 1/2 LCD screen
  2. Super range indication: the LCD screen will display “OL”
  3. Low battery indication: when the battery voltage is lower than the normal working voltage, “ ” will be displayed on the screen.
  4. Input polarity indication: automatically display “-”
  5. Maximum voltage allowed between the measuring terminal and the ground: DC or AC 600V RMS
  6. Power supply: 2x1.5V AAA batteries
  7. Dimension: 225x38x26mm
  8. Weight: 110 grams (approx.)
  9. Size: 205 x 38 x 29 cm (80.7 x 15 x 11.4 in)
  10. Safety rating: EN61010-1, -2-030, EN61010-2-033, EN61326-1, CAT.III 600V
  11. The accuracy applies within one year after the calibration.
  12. Reference condition: the environment temperature 18°C to 28°C,
  13. the relative humidity is no more than 80%.

Specifications

SPECIFICATIONS RANGE ACCURACY
DC Voltage 200mV/2V/20V/200V/600V ±(0.7%+2)
AC Voltage 200mV/2V/20V/200V ±(0.8%+3)
600V ±(1.0%+3)
DC Current 20mA/200mA ±(1.5%+3)
AC Current 20mA/200mA ±(2.0%+3)
Resistance(Ω) 200Ω/2kΩ/20kΩ/200kΩ/2MΩ ±(1.0%+3)
20MΩ ±(1.0%+5)
FEATURE
Display 2000 counts
Data Hold
Diode test
Continuity
NCV
Work Light
GENERAL
Power Supply 2×1.5V AAA Battery
Weight Approx.110g
Size 248mm×42mm×34mm
Safety Rating EN61010-1,EN61010-2-033, EN61326,CATⅢ600V
