Intelli-Check Professional Insulation and Continuity Tester with Comprehensive Data Management and Safety

Name: IntelliCheck Professional Insulation and Continuity Tester with Comprehensive Data Management and Safety
Brand: PEAKMETER
Price: 1 USD

China Intelli-Check Professional Insulation and Continuity Tester with Comprehensive Data Management and Safety wholesale

Brand Name : PEAKMETER

Model Number : MS5208

Certification : CE

Place of Origin : China

MOQ : 1

Price : Negotiation

Payment Terms : T/T

Supply Ability : 150,000 Pcs Per Month

Delivery Time : 5-40 work days

Packaging Details : Product Size: 200mm * 155mm * 76mm Product Weight : Approx. 500g

Function 1 : High Precision and Wide Range

Insulation Resistance Range : 0.01MΩ~2499MΩ

Function 2 : Safety Design

Versatile Measurements : Continuity Resistance Measurement, AC/DC Voltage Measurement

Function 3 : Data Management and Automatic Calculation

Certified Safety Standards : EN61010-1, EN50581, EN61326-1 CAT.III 1000V CAT.IV 600V Standards

Contact Now

High Voltage Insulation Resistance Continuity Tester with Multi-Voltage Output and Precision Measurement

Key Fatures and Technical Specifications of Digital Insulation ResistanceTester

Auto Calculats PI and DAR
Data Storage
Continuous Resistance Measurement
Timer Function for insulation test
Lock function for insulation test
DCV and ACV Test
Clear Function
Auto power Off
Backlight and Double Display

Insulation Resistance Test
	Range	Accuracy	Shot-Circuit
100V	0.00MΩ~249MΩ	±(3%+5)	＞1.5mA
	0.25GΩ~2.49GΩ	±(10%+5)
	2.5GΩ~10.0GΩ	±20%
250V	0.00MΩ~249MΩ	±(3%+5)
	0.25GΩ~2.49GΩ	±(10%+5)
	2.5GΩ~25.0GΩ	±20%
500V	0.00MΩ~249MΩ	±(3%+5)
	0.25GΩ~29.9GΩ	±(10%+5)
	30GΩ~50GΩ	±20%
1000V	0.00MΩ~249MΩ	±(3%+5)
	0.25GΩ~29.9GΩ	±(10%+5)
	30GΩ~100GΩ	±20%
2500V	0.00MΩ~249MΩ	±(3%+5)
	0.25GΩ~29.9GΩ	±(10%+5)
	30GΩ~300GΩ	±20%
Voltage measurement
	Range	Accuracy
ACV	20~750V(50/60Hz)	±(2%+3)
DCV	±20V~±1000V	±(2%+3)
Continuity Test
Output Voltage	Range	Accuracy
4.8V~5.3V	0.00~9.99Ω	±(1.5%+5)
	10.0~99.9Ω	±(1.5%+5)
	100~300Ω	±(1%+5)
Featurel
Auto caculate PI and DAR	√
Auto discharge function	√
Zero function	√
Back light	√
Auto power off	√
Data logging	99 Groups
General
Power Supply	1.5V LR6*6
Size	20015576mm
Weight	500g

Product Description of Digital Insulation ResistanceTester

High Voltage Insulation Resistance Continuity Tester MS5208 features multi-voltage output, high precision measurement, safety functions, user-friendly design, versatile measurement capabilities, and data management with automatic calculations. It is ideal for testing insulation and continuity in power equipment, supply lines, and new energy vehicles.

Multi-Voltage Output: Adjustable output voltages (100V, 250V, 500V, 1000V, 2500V) to meet various testing requirements.
High Precision and Wide Range: Ensures accurate measurements and reliable data, suitable for professional use.
Safety Design: Features automatic discharge to eliminate residual voltage and a live alarm for real-time safety alerts.
Data Management and Calculation: Equipped with data storage and automatic calculation of Polarization Index (PI) and Dielectric Absorption Ratio (DAR) for comprehensive analysis.
Certified Safety Standards: Complies with EN61010-1, EN50581, EN61326-1 CAT.III 1000V CAT.IV 600V standards, ensuring high safety and performance.
